Redbird
Type H Metal Roof Deck
Long Span Deck
Type LS Metal Roof Deck
Type F Metal Roof Deck (Intermediate Rib)
Type F Metal Roof Deck is a 1 1/2 deep, intermediate rib metal roof deck that provides an economical roofing system of structural load carrying capacity and roofing insulation materials. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type F Metal Roof Deck is commonly produced in three gauges and a 36” cover width with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat).
Type N Metal Roof Deck (Deep Rib)
Type N Metal Roof Deck is a 3 tall, deep rib metal roof deck, that is designed to provide an economical roofing support surface when longer spans are required between roofing supports. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type N Metal Roof Deck is available in 24” cover width and three standard gauges, with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat). Please inquire for availability of special gauges or finishes. N-Acoustical, N-Cellular, and N-Cellular & Acoustical are also available (longer lead times may be required).
Type F Metal Roof Deck (Intermediate Rib)
Type F Metal Roof Deck is a 1 1/2 deep, intermediate rib metal roof deck that provides an economical roofing system of structural load carrying capacity and roofing insulation materials. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type F Metal Roof Deck is commonly produced in three gauges and a 36” cover width with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat).
Type N Metal Roof Deck (Deep Rib)
Type N Metal Roof Deck is a 3 tall, deep rib metal roof deck, that is designed to provide an economical roofing support surface when longer spans are required between roofing supports. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type N Metal Roof Deck is available in 24” cover width and three standard gauges, with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat). Please inquire for availability of special gauges or finishes. N-Acoustical, N-Cellular, and N-Cellular & Acoustical are also available (longer lead times may be required).
Steel Form Deck
Type F Metal Roof Deck (Intermediate Rib)
Type F Metal Roof Deck is a 1 1/2 deep, intermediate rib metal roof deck that provides an economical roofing system of structural load carrying capacity and roofing insulation materials. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type F Metal Roof Deck is commonly produced in three gauges and a 36” cover width with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat).
Type N Metal Roof Deck (Deep Rib)
Type N Metal Roof Deck is a 3 tall, deep rib metal roof deck, that is designed to provide an economical roofing support surface when longer spans are required between roofing supports. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type N Metal Roof Deck is available in 24” cover width and three standard gauges, with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat). Please inquire for availability of special gauges or finishes. N-Acoustical, N-Cellular, and N-Cellular & Acoustical are also available (longer lead times may be required).
Steel Form Deck
Type F Metal Roof Deck (Intermediate Rib)
Type F Metal Roof Deck is a 1 1/2 deep, intermediate rib metal roof deck that provides an economical roofing system of structural load carrying capacity and roofing insulation materials. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type F Metal Roof Deck is commonly produced in three gauges and a 36” cover width with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat).
Type N Metal Roof Deck (Deep Rib)
Type N Metal Roof Deck is a 3 tall, deep rib metal roof deck, that is designed to provide an economical roofing support surface when longer spans are required between roofing supports. It is also used as a secondary structural diaphragm member to provide for lateral force distribution to the structure’s vertical force resisting systems. Type N Metal Roof Deck is available in 24” cover width and three standard gauges, with either a galvanized finish or prime painted to inhibit rust while in transit (primer is not a finish coat). Please inquire for availability of special gauges or finishes. N-Acoustical, N-Cellular, and N-Cellular & Acoustical are also available (longer lead times may be required).
Steel Form Deck
Steel Form Deck
Steel Form Deck
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
Design Thickness
22 ga. (.0295)
20 ga. (.0358)
18 ga. (.0474)
16 ga. (0.600)
Available Finish
Galvanized G-60
Galvanized G-90
Prime Painted Gray
